The WB-5 Wide Body bipod is expertly designed to provide the desired height and enhanced stability for precision shooting. This style is ideal for long-range, extreme long-range, bench-rest shooting, and airsoft platforms. Its wide, lowered center design allows the rifle to sit comfortably between the legs, promoting accuracy and reducing recoil movement. While tailored for these uses, its versatility extends beyond them.
Crafted from 100% billet aircraft-grade aluminum, the WB-5 offers exceptional durability and performance. It features four leg-angle positions and nine height adjustments, ensuring adaptability to a range of shooting environments. Additionally, the bipod includes a canting function that can be securely locked and adjusted with the lever for precise control.
With its robust construction and reliable versatility, the WB-5 is a top-tier choice for shooters demanding stability and accuracy.
|
Picatinny |
Arca | |
| Materials | 6061 T6 Aluminum alloy / High strength steel hardware | 6061 T6 Aluminum alloy / High strength steel hardware |
| Min. Height (Legs at 45°) | 5.5” / 140 mm | 5.75” / 146.05 mm |
| Min. Height (Legs at 90°) | 7.25" / 184.15 mm | 7.5" / 190.5 mm |
| Max. Height (Legs at 90°) | 10” / 254 mm | 10.25” / 260.35 mm |
| Min. Stance (Legs at 45°) | 11" / 279.4 mm | 11" / 279.4 mm |
| Max. Stance (Legs at 90°) | 17.25" / 438.15 mm | 17.25" / 438.15 mm |
| Closed Position Width | 5" / 127 mm | 5" / 127 mm |
| Closed Position Length | 9” / 228.6mm | 9” / 228.6mm |
| Weight | 23.92 oz | 23.92 oz |
| Color | Flat Black | Flat Black |
| Coating | Type III ( MIL-SPEC ) Hard Anodize | Type III ( MIL-SPEC ) Hard Anodize |
